Resistor color code calculator
Find a resistor's value from its colored bands, or see which colors a value is written with. For 4 and 5 band resistors.
From colors to a value
220 Ω
Resistor 220 Ω (1/4W) · shop prices and the projects that use it
From a value to colors
Color chart
| Color | Digit | Multiplier | Tolerance |
|---|---|---|---|
| Black | 0 | ×1 | |
| Brown | 1 | ×10 | ±1% |
| Red | 2 | ×100 | ±2% |
| Orange | 3 | ×1,000 | |
| Yellow | 4 | ×10,000 | |
| Green | 5 | ×100,000 | ±0.5% |
| Blue | 6 | ×1,000,000 | ±0.25% |
| Violet | 7 | ×10,000,000 | ±0.1% |
| Grey | 8 | ×100,000,000 | ±0.05% |
| White | 9 | ×1,000,000,000 | |
| Gold | ×0.1 | ±5% | |
| Silver | ×0.01 | ±10% |
How to read it
Hold the resistor with the gold or silver band on the right and read from the left. On a 4 band resistor the first two bands are digits, the third the multiplier and the last the tolerance: red, red, brown, gold = 22 × 10 = 220 Ω, ±5%. On a 5 band resistor the first three bands are digits. When the colors are faded, or brown and orange look alike, a multimeter on its resistance range is the surest way.
